CHF 3.29
Do you have some questions about this product?
- Your personal contact person
- Name: Aco Gorgiev
- E-Mail: aco@normrahmen.ch
- Phone: +41 31 744 10 45
-
Product Manager, Customer Consultancy Electrical Engineering, Production
Product information "CAT 6A slim patch cable, S/FTP, 1000mm, green, LSZH halogen-free, 500 Mhz"
| AWG: | 32/7 (stranded) |
|---|---|
| Cable length: | 1.00 m |
| Cable sheath, material: | LSZH |
| Cable sheath diameter (approx.): | 4 mm |
| Cable type: | Round cable (Slim) |
| Colour: | green |
| Connection 1, type: | RJ 45 plug (8P8C) |
| Connection 2, type: | RJ 45 plug (8P8C) |
| Connection shielding: | Yes |
| Contacting: | EIA/TIA-568C.2 |
| Halogen-free: | Yes |
| Inner conductor, material: | CU (copper) |
| Kink protection: | on both sides |
| LSZH-compliant: | Yes |
| Latching nose guard: | on both sides |
| Max. Bandwidth: | 500 MHz |
| Number of shields: | 2 x |
| Operating temperature from: | -20 °C |
| Operating temperature up to: | 60 °C |
| Shielding class: | S/FTP (PiMF) |
| Specification: | CAT 6A |
| UL: | No |
