Product information "Janitza multifunctional network analyser with RCM, UMG 509-PRO"
The UMG 509-PRO is a powerful network analyser with residual current monitoring and can measure harmonics up to the 63rd harmonic. The analyser is used in all levels of TN & TT networks as well as in IT networks for monitoring voltage quality, residual current monitoring and energy data management. It also has a 256 MB measurement data memory and can be graphically programmed with Jasic (PLC functionality). Network interfaces and the open communication architecture with numerous protocols (Modbus, IP) enable simple integration into higher-level systems. Two digital inputs and outputs and a temperature measurement input are available at field level.
| 4th current transformer input: | Yes |
|---|---|
| Accuracy A: | 0.2% |
| Accuracy V: | 0.1% |
| Active energy class: | 0.2S (.../5 A) |
| Analogue output: | None |
| Asymmetry: | Yes |
| Clock: | Yes |
| Current measuring channels: | 4 |
| Digital / pulse output: | 2 |
| Digital inputs: | 2 |
| Distortion factor THD-U / THD-I in %: | Yes |
| Execution of the interface: | Modbus RTU RS485, Profinet, TCP/IP (Ethernet / network) |
| Fault recorder function: | Yes |
| Harmonics V/A: | 1.-63. |
| Integrated logic: | Jasic (7 prg.) |
| Memory min / max values: | Yes |
| Memory size: | 256 MB |
| Quadrants: | 4 |
| Residual current inputs: | 2 |
| Sampling frequency 50/60 Hz: | 20 kHz |
| Short-term interruptions: | Yes |
| Short / long-term flicker: | No |
| Supply voltage: | 90 - 265V AC & 90 - 250V DC |
| Temperature input: | 1 |
| Transients: | > 50 µs |
| Web server / e-mail: | Yes |
