CHF 55.64
Do you have some questions about this product?
- Your personal contact person
- Name: Tobias Schneider
- E-Mail: tobias@normrahmen.ch
- Phone: +41 31 744 10 42
-
Head of Product Development and Consultancy, Management Board
Product information "Miniature circuit-breaker, ETIMAT P10, 3-pole+N, characteristic C / 25A, 10kA"
| Characteristic: | C |
|---|---|
| Connection cross-section (flexible): | 1-25 mm2 |
| Connection technology: | Screw terminal |
| Frequency: | 50 & 60 Hz |
| Halogen-free: | Yes |
| Height: | 74.5 mm |
| Length: | 89 mm |
| Number of poles: | 4 |
| Number of wiring points: | 8 |
| Operating temperature from: | -40 °C |
| Operating temperature up to: | 75 °C |
| Protection class: | IP 20 |
| Rated current: | 25A |
| Short-circuit resistance: | 10kA |
| Width: | 71.2 mm |
| Width in pitch units: | 4 Module |
Accessories for miniature circuit-breaker, ETIMAT P10, 3-pole+N, characteristic C / 25A, 10kA
56MOD, conducteur de phase réparti (L1, L2, L3, N.....) raccordement latéral max. 80A, raccordement au milieu max. 130A compatible avec Etimat P10 (3PN), EFI-4, KZS-4M IZ16/4F/56 (longueur totale 1010mm)
Content: 1 Piece (CHF 1,006.78 / 10 Piece)
Content: 1 Piece (CHF 346.33 / 10 Piece)
Content: 1 Piece (CHF 220.15 / 10 Piece)
