CHF 193.9314
Do you have some questions about this product?
- Your personal contact person
- Name: Tobias Schneider
- E-Mail: tobias@normrahmen.ch
- Phone: +41 31 744 10 42
-
Head of Product Development and Consultancy, Management Board
Product information "NH fuse-switch disconnectors size 00, 3P, 185mm, M8 (1-pole switchable) U5"
| Cable connection: | Flat connection M8 |
|---|---|
| Colour: | grey |
| Conditional rated short-circuit current Icc: | 100kA (AC500V) |
| Electronic fuse monitoring (ESÜ): | No |
| Max. Rated operating current Ie: | 160A |
| Max. Rated operating voltage Ue: | 690V |
| Mounting type: | 185mm system |
| Number of poles: | 3 |
| Size: | NH00 |
| Suitable for transformer installation: | No |
| Switchability: | 1-pole switchable |
| Top or bottom outlet: | below, top |
| With integrated feed-in connection: | No |
Accessories for NH fuse-switch disconnectors size 00, 3P, 185mm, M8 (1-pole switchable) U5
1set of contact hooks E³ 00/185 Eh 150mm
Lateral support bracket LV for fixing the cover strip profiles
1 set (3 pieces) thrust pieces E³ size 00
1 set (3 pieces) contact prisms E³ size 00
1 SET (3 PIECES) CONTACT PRISMS E300/185
Switch cover E³ size 00/185 1P EFEN
