Product information "Phase inverter CEE plug 16A 5P 6h, 3PNE 400V, nickel-plated contacts, screw connection"
| Cable entry: | Screw connection |
|---|---|
| Cable strain relief: | Yes |
| Clock position: | 6h |
| Connection cross-section (flexible): | 1.0-2.5 mm2 |
| Connection cross-section (rigid): | 1.0-4.0 mm2 |
| Connection technology: | Screw terminal |
| Connection type: | Screw connection |
| Contacts: | nickel-plated |
| Frequency: | 50 & 60 Hz |
| Identification colour: | red |
| Insertion direction: | straight |
| Locking system housing: | 1-point twist lock |
| Material: | Plastic |
| Number of poles: | 5 |
| Number of wiring points: | 5 |
| Phase inverter: | Yes |
| Pole conductor connection depth max.: | 13mm |
| Protection class: | IP 44 |
| Rated current: | 16A |
| Rated voltage: | 400V |
Accessories for phase inverter CEE plug 16A 5P 6h, 3PNE 400V, nickel-plated contacts, screw connection
Customers also bought
High-quality phase inverter CEE plug from the TP-Electric brand, specially developed for areas exposed to extreme conditions such as rain, acids, dirt etc.... The nickel-plated contacts of this plug are the optimal protection against corrosion and rust. The locking system of this plug is also well thought out because with many conventional plugs it has to be pushed in with a screwdriver to open them, which can quickly lead to dangerous situations. With our system, only a 90 degree turn with the screwdriver is required to open or close it. Our TP-Electric products are of European origin and also VDE tested, unlike other products from the Far East.
High-quality CEE plug from the TP-Electric brand. This plug has been specially developed for areas exposed to extreme conditions such as rain, acids, dirt etc.... The nickel-plated contacts of this plug provide optimum protection against corrosion and rust, while the patented quick-connection system ensures optimum retention compared to conventional screw connections. Simply put, vibrations are no longer an issue, as is the over-tightening of screw terminals. Apart from that, this Quick Connect system is also much quicker to install than the screw connections. Quick-Connect is the safest system on the market and the locking system of these plugs is also well thought out because with many conventional plugs you have to push them in with a screwdriver to open them, which can quickly lead to dangerous situations. With our system, only a 90 degree turn of the screwdriver is required to open or close it. Our TP-Electric products are of European origin and are also VDE tested, unlike other products from the Far East.
