CHF 90.9932
Do you have some questions about this product?
- Your personal contact person
- Name: Tobias Schneider
- E-Mail: tobias@normrahmen.ch
- Phone: +41 31 744 10 42
-
Head of Product Development and Consultancy, Management Board
Product information "Tubular current transformer compact (encapsulated) 400/5A, 2.5VA, class 0.5s, with 3 metre cable (4mm2)"
| Accuracy class: | Class 0.5s |
|---|---|
| Apparent electrical power: | 2.5VA |
| Cable length: | 3.00 m |
| Calibratable: | No |
| Calibrated: | No |
| Colour: | black |
| Frequency: | 50 & 60 Hz |
| Halogen-free: | Yes |
| Max. Cable diameter: | 21mm |
| Rated current: | 400A |
| Transformer ratio: | 400/5A |
Accessories for tubular rod current transformer compact (encapsulated) 400/5A, 2.5VA, class 0.5s, with 3 metre cable (4mm2)
