Product information "NH fuse-switch disconnectors size 00, 3P, 100mm, M8 (1-pole switchable) "hook mounting" U5"
including contact hooks
| Cable connection: | Flat connection M8 |
|---|---|
| Conditional rated short-circuit current Icc: | 100kA (AC500V) |
| Electronic fuse monitoring (ESÜ): | No |
| Max. Rated operating current Ie: | 160A |
| Max. Rated operating voltage Ue: | 690V |
| Mounting type: | 100mm system |
| Number of poles: | 3 |
| Size: | NH00 |
| Suitable for transformer installation: | No |
| Switchability: | 1-pole switchable |
| Top or bottom outlet: | below, top |
| With integrated feed-in connection: | No |
Accessories for NH fuse-switch disconnectors size 00, 3P, 100mm, M8 (1-pole switchable) "Hook fastening" U5
1 set (3 pcs.) E³ hook size 00/100/185
Capot d'espace de raccordement long pour Gr.00/60 et 00/100
Capot d'espace de raccordement court pour Gr.00/60 et 00/100
Lateral support bracket LV for fixing the cover strip profiles
