CHF 183.34
Do you have some questions about this product?
- Your personal contact person
- Name: Tobias Schneider
- E-Mail: tobias@normrahmen.ch
- Phone: +41 31 744 10 42
-
Head of Product Development and Consultancy, Management Board
Product information "NH fuse-switch disconnectors size 00, 3P, 185mm, M8 (3-pole switchable) mini version, U5"
| Cable connection: | Flat connection M8 |
|---|---|
| Colour: | grey |
| Conditional rated short-circuit current Icc: | 100kA (AC500V) |
| Electronic fuse monitoring (ESÜ): | No |
| Max. Rated operating current Ie: | 160A |
| Max. Rated operating voltage Ue: | 690V |
| Mounting type: | 185mm system |
| Number of poles: | 3 |
| Size: | NH00 |
| Suitable for transformer installation: | No |
| Switchability: | 3-pole switchable |
| Top or bottom outlet: | below, top |
| With integrated feed-in connection: | No |
Accessories for NH fuse-switch disconnectors size 00, 3P, 185mm, M8 (3-pole switchable) mini version, U5
1 set (3 pcs.) E³ hook size 00/100/185
Lateral support bracket LV for fixing the cover strip profiles
Shift cover E³ size 00/185 3P EFEN
Double adapter 185/185
Double adapter E3 185/185 Bh
